3.3V 233MHz AMD-K6
TM
Processor Specifications
This document is designed to provide information on the product marking, electrical
specifications, recommended motherboards, and recommended thermal solutions for the
3.3V 233 MHz AMD-K6 processor.
Product Nomenclature
Figure 1 below illustrates the product marking and valid Ordering Part Number (OPN) for
the 3.3V 233 MHz AMD-K6 processor.
Name
Voltage
Major Revision
Date Code
Copyright
Microsoft Logo
AMD
AMD-K6
TM
OPN
AMD-K6-233APR
Designed for
AMD-K6-233APR
3.3V CORE/3.3V I/O
C 9710APB
m c 1997 AMD
MALAY
AAAAA
I
Top Mark
Case Temperature
R = 0擄C-70擄C
Operating Voltage
P = 3.2V-3.4V (Core) / 3.135V-3.6V (I/O)
Package Type
A = 321-pin CPGA
Performance Rating
-233
Family/Core
AMD-K6
Figure 1. Product Marking for the 3.3V 233 MHz AMD-K6 Processor
Electrical Specifications
Table 1 contains the electrical specifications for the 3.3V 233 MHz AMD-K6 processor.
Table 1.
V
CC2
V
CC3
I
CC2
Max
I
CC3
Max
Case Temperature (T
C
)
Electrical Specifications for the 3.3V 233 MHz AMD-K6 Processor
3.3V +/- 100 mV
3.3V +300 mV/-165 mV
9.75 A
0.52 A
0 deg C - 70 deg C
Maximum Thermal Power
Typical Thermal Power
Maximum Power, Stop Grant/Halt
Maximum Power, Stop Clock
30.2 W
18.2 W
1.8 W
1.0 W
AMD-K6 is a trademark of Advanced Micro Devices, Inc.
漏 1997, Advanced Micro Devices, Inc. All rights reserved.
