Alcatel 1948 PLO
High power 1480 nm
Pump Laser module
Description
Features
The Alcatel 1948 PLO module
contains a SLMQW 1480 nm high
power laser directly coupled to the
pigtail.
It incorporates a thermo-electric
cooler, precision NTC thermistor, and
a monitor photodiode. The
Alcatel 1948 PLO can be pigtailed
with a standard Single Mode Fiber
(SMF) or a Polarization Maintaining
Fiber (PMF).
The Alcatel 1948 PLO is dedicated to
1480 nm pumped Erbium-Doped
Fiber Amplifiers (EDFA).
鈥?From 140 to 200 mW output
power versions
鈥?Low drive current
鈥?SMF or PMF
鈥?InGaAsP SLMQW laser
鈥?Internal TEC and monitor
photodiode
鈥?Hermetic 14-pin butterfly package
鈥?Full performance in operating case
temperature from 0 to + 70 擄C
Applications
鈥?High power EDFA
鈥?Instrumentation
Optical characteristics
Parameter
Threshold current (Ith)
Output power (Pf)
If = 700 or 600 mA
If = 700 or 600 mA
If = 700 or 600 mA
If = 700 or 800 mA
If = 800 mA
Forward voltage (Vf)
Monitoring current
Wavelength range
Spectral width (RMS)
Photodiode dark current
Photodiode capacitance
Thermistor resistance
TEC current (Itec)
TEC voltage (Vtec)
鈭員
= 45擄C; Tchip = 25擄C; Tcase = 70擄C
鈭員
= 45擄C; Tchip = 25擄C; Tcase = 70擄C
- 10 dB
V= - 5V
V= - 5V, 1 MHz
9.5
@ If
@ If
300
1460
1490
15
50
15
10.5
1.3
4.2
140
160
180
190
200
Condition
Min
Typical
35
155
175
200
210
220
2.1
Max
65
Unit
mA
mW
mW
mW
mW
mW
2.5
V
碌A(chǔ)
nm
nm
nA
pF
k
