Through-Beam Photoelectric
Sensor / NAMUR
OCE30M-F5-N2S
30 m
Features
聲 Intrinsically safe, Identification code:
EEx ia IIC T6
PTB Nr. Ex-97.D.2264
聲 Visible red light
聲 Light/dark ON, wiring dependent
聲 Noise immune
聲 Terminal compartment
聲 Protection class IP 64
Mounting aids etc. see "Accessories" section.
Electrical Connection
Receiver
(1) 1
T
(2) 4
N.C. (Light ON)
N.O. (Dark ON)
Terminal 1,2
Terminal 1,4
L+
L-
Emitter
1
T
2
L+
27.04.1998
Copyright Pepperl+Fuchs, Printed in Germany
Date of issue
L-
196
Subject to reasonable modifications due to technical advances.
