GaAlAs T-1 PACKAGE
INFRARED EMITTING DIODE
Description
The MIE-364L3 is a GaAlAs infrared LED having a
peak wavelength at 880nm. It features high power,
and molded in water clear plastic package with higher
radiant intensity.
4.55
(.179)
蠄3.10
(.122)
3.85
(.152)
MIE-364L3
Package Dimensions
Unit : mm (inches )
1.50
(.059)
.50
(.019)
23.40MIN
(.920)
Features
l
l
l
l
High radiant intensity
Standard T-1 (
蠁
3mm ) package
Peak wavelength
位
p
= 880 nm
Radiant angle : 35擄
.50 TYP.
(.020)
1.00 MIN.
(.040)
2.54
(.100)
A
C
Notes :
1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 0.5 mm (.019") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
120
1
100
5
-55
o
C to +100
o
C
-55
o
C to +100
o
C
260
o
C for 5 seconds
Unit
mW
A
mA
V
Unity Opto Technology Co., Ltd.
02/04/2002
1
2
