.100鈥?PCB
Four Row
S
Low profile
S
Standard staggered grid
S
Variety of pin lengths and plating options available
Date Modified: February 19, 1999
2
TS-0005-09
Sheet 1 of 2
Physical
Insulation
Material:
Flammability:
Color:
Contact
Material:
Plating
Underplate:
U-Slot & Solder Tails:
Glass Filled Polyester (PBT)
UL 94V-0
Gray
Copper Alloy
100
碌鈥?/div>
[2.54
碌m]
Nickel 鈥?QQ-N-290, Class 2
10
碌鈥?/div>
[0.25
碌m]
Gold 鈥?MIL-G-45204, Type II, Grade C
or 200
碌鈥?/div>
[5.08
碌m]
Tin Lead
Wire Accommodation:
26 & 28 AWG Solid or Stranded
Marking:
3M Logo and Part Identification Number
Electrical
Current Rating:
1 A
Insulation Resistance:
> 1
脳
10
9
鈩?/div>
at 500 VDC
Withstanding Voltage:
1000 Vrms at Sea Level
Environmental
Temperature Rating:
鈥?55擄C to +120擄C
UL File No.: E68080
3M Interconnect Solutions Division
6801 River Place Blvd.
Austin, TX 78726-9000
For technical, sales or ordering information call
800-225-5373
