GaAlAs T-1 PACKAGE
INFRARED EMITTING DIODE
Description
The MIE-324H4 is a GaAlAs infrared LED having a
peak wavelength at 850nm. It features ultra-high power,
high response speed and molded package with higher
radiant intensity. In addition to improving the S/N ratio
in applied optical systems, the MIE-324H4 has greatly
improved long-distance characteristics as well as sign-
ificantly increased its range of applicability .
SEE NOTE
蠁
3.50鹵0.25
(.138鹵.010)
蠁
3.10鹵0.20
(.122鹵.008)
4.10鹵0.20
(.161
鹵.008)
MIE-324H4
Package Dimensions
Unit : mm (inches )
5.20鹵0.30
(.205鹵.012)
4.00
(.157
24.00MIN
.
CATHODE
Features
l
l
l
l
0.50 TYP.
(.020)
Ultra-High radiant intensity
High response speed
Standard T-1 (
蠁
3mm ) package, radiant angle : 40擄
Peak wavelength
位
p
= 850 nm
1.00MIN
.
(.040)
2.54NOM.
(.100)
SEE NOTE 3
A
C
Notes :
1. Tolerance is 鹵0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 1.5 mm (.059") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current(300pps,10碌s pulse)
Continuos Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
120
1
100
5
-55
o
C to +100
o
C
-55
o
C to +100
o
C
260
o
C for 5 seconds
Unit
mW
A
mA
V
Unity Opto Technology Co., Ltd.
02/04/2002
