3134
BIPOLAR HALL-EFFECT SWITCH
FOR HIGH-TEMPERATURE OPERATION
This low-hysteresis bipolar Hall-effect switch is an extremely
temperature-stable and stress-resistant sensor especially suited for
operation over extended temperature ranges to +150擄C. Superior
high-temperature performance is made possible through a novel Schmitt
trigger circuit that maintains operate and release point stability by
compensating for temperature changes in the Hall element. Additionally,
internal compensation provides magnetic switch points that become more
sensitive with temperature, hence offsetting the usual degradation of the
magnetic field with temperature. Its low hysteresis makes this device
ideal for detecting small changes in magnetic field strength or for use
with inexpensive magnets.
The device includes on a single silicon chip a voltage regulator,
quadratic Hall-voltage generator, temperature compensation circuit,
signal amplifier, Schmitt trigger, and a buffered open-collector output to
sink up to 25 mA. The on-board regulator permits operation with supply
voltages of 4.5 volts to 24 volts.
The first character of the part number suffix determines the device
operating temperature range. Suffix 鈥楨鈥撯€?is for -40擄C to +85擄C, and
suffix 鈥楲鈥撯€?is -40擄C to +150擄C. Two package styles provide a magneti-
cally optimized package for most applications. Suffix 鈥樷€揕T鈥?is a minia-
ture SOT89/TO-243AA transistor package for surface-mount applica-
tions while suffix 鈥樷€揢A鈥?is a three-lead ultra-mini-SIP.
Data Sheet
27631.4D
V
X
CC
1
2
3
GROUND
Dwg. PH-003A
Pinning is shown viewed from branded side.
ABSOLUTE MAXIMUM RATINGS
at T
A
= +25
擄
C
Supply Voltage, V
CC
.............................
30 V
Reverse Battery Voltage, V
RCC
..........
-30 V
Magnetic Flux Density, B ..........
Unlimited
Output OFF Voltage, V
OUT
..................
30 V
Reverse Output Voltage, V
OUT
...........
-0.5 V
Continuous Output Current,
I
OUT
............................................
25 mA
Operating Temperature Range, T
A
Suffix 鈥楨鈥撯€?..................
-40
擄
C to +85
擄
C
Suffix 鈥楲鈥撯€?................
-40
擄
C to +150
擄
C
Storage Temperature Range,
T
S
..............................
-65
擄
C to +170
擄
C
OUTPUT
SUPPLY
FEATURES
s
Superior Temperature Stability
s
Operation From Unregulated Supply
s
Open-Collector 25 mA Output
s
Reverse Battery Protection
s
Activate With Small, Commercially Available Permanent Magnets
s
Solid-State Reliability
s
Small Size
s
Resistant to Physical Stress
Always order by complete part number, e.g.,
A3134ELT
.
