Model 3052
Vibration/Shock Monitoring
PC Board Mountable Accelerometer
Millivolt Output
Integral Temperature Compensation
Modal Analysis
Motion Control
Crash Testing
Aerospace
DESCRIPTION
The Model 3052 is a piezoresistive silicon accelerometer with
integral temperature compensation. It is packaged on a ceramic
substrate with an epoxy sealed ceramic cover and is designed for
adhesive mounting.
The accelerometer consists of a micro machined silicon
mass suspended by multiple beams from a silicon frame.
Piezoresistors located in the beams change their resistance as the
motion of the suspended mass changes the strain in the beams.
Silicon caps on the top and bottom of the device are added to
provide over-range stops. This design provides for a very low
profile, high shock resistance, durability and built-in damping
over a wide usable bandwidth. Each sensor is individually
serialized.
For an accelerometer with a mounting bracket which can be
FEATURES
Adhesive Mount
鹵0.5% Non-linearity (typical)
鹵1.0% Temperature Performance
(typical)
DC Response
Built-in Damping
Built-in Overrange Stops
Low Power
used to bolt the sensor to the mounting location see the Model
3058. For uncompensated accelerometers, please refer to the
Models 3022 and 3028.
STANDARD RANGES
Range
鹵2
鹵5
鹵10
g
Range
鹵20
鹵50
鹵100
g
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
鈼?/div>
2-20
Accelerometer 鈥?Unamplified
3052-050-P 產(chǎn)品屬性
10
傳感器，轉(zhuǎn)換器
加速計
-
X 或 Y
±50g
0.3mV/g
2 V ~ 10 V
模擬
500Hz
-
表面貼裝
粘貼安裝
-
