M80C196KB

16-BIT HIGH PERFORMANCE CHMOS

MICROCONTROLLER

Military

Y

Y

Y

Y

Y

Y

Y

Y

Y

Y

232 Byte Register File

Register-to-Register Architecture

28 Interrupt Sources 16 Vectors

2 3

ms

16 x 16 Multiply (12 MHz)

4 0

ms

32 16 Divide (12 MHz)

Powerdown and Idle Modes

Five 8-Bit I O Ports

16-Bit Watchdog Timer

Dynamically Configurable 8-Bit or

16-Bit Buswidth

Available in 68-Lead PGA and 68-Lead

Ceramic Quad Flat Pack

Y

Y

Y

Y

Y

Y

Y

Y

Y

Full Duplex Serial Port

High Speed I O Subsystem

16-Bit Timer

16-Bit Up Down Counter with Capture

Pulse-Width-Modulated Output

Four 16-Bit Software Timers

10-Bit A D Converter with S H

12 MHz Version

M80C196KB

Available in Two Product Grades

MIL-STD-883

b

55 C to

a

125 C (T

C

)

Military Temperature Only (MTO)

b

55 C to

a

125 C (T

C

)

The M80C196KB 16-bit microcontroller is a high performance member of the MCS -96 microcontroller family

The M80C196KB is pin-for-pin compatible and uses a true superset of the M8096 instructions Intel鈥檚 CHMOS

process provides a high performance processor along with low power consumption To further reduce power

requirements the processor can be placed into Idle or Powerdown Mode

Bit byte word and some 32-bit operations are available on the M80C196KB With a 12 MHz oscillator a 16-bit

addition takes 0 66

ms

and the instruction times average 0 5

ms

to 1 5

ms

in typical applications

Four high-speed capture inputs are provided to record times when events occur Six high-speed outputs are

available for pulse or waveform generation The high-speed output can also generate four software timers or

start an A D conversion Events can be based on the timer or up down counter

Also provided on-chip are an A D converter with Sample and Hold serial port watchdog timer and a pulse-

width-modulated output signal

271089鈥?1

Figure 1 M80C196KB Block Diagram

October 1993

Order Number 271089-006
