OEM PQFP Sockets
鈥?Accepts JEDEC MO-069 packages, lead
counts 84, 100 and 132
鈥?.025"(0.64mm) center line contacts for
high-density packaging
鈥?Lid design separates, maintains IC lead
spacing
鈥?Lid acts as package carrier and transport
protector
鈥?Lid is compatible with conventional package
shipping tubes and trays
鈥?Slotted, 鈥渙pen鈥?socket walls and corners
permit airflow around capturedpackage (aids
in package heat dissipation)
鈥?Latches secure lid/package assembly to base
鈥?Mirror image contact pin-out available on
most lead counts
鈥?Required tooling available in two styles
TS-0361-10
Sheet 1 of 4
Date Issued: November 1, 1999
8.
Physical
Insulation
Material:
Flammability:
Color:
Contact
Material:
Plating
Underplate:
Wiping Area & Solder Tails:
Latching Aid
Material:
Color:
Marking:
Glass Filled Polyethersulfone ( PES )
UL 94V-0
Black
Beryllium Copper
50
m
"
[ 1.27
m
m ] Nickel
200
m
"
[ 5.08
m
m ] 60/40 Tin Lead
Polycarbonate (PC)
Black
Raised Letters: 3M Logo & Part Identification
Electrical
Current Rating:
1 A
Insulation Resistance:
> 1
樓
10
12
W
at 500 Vdc
Withstanding Voltage:
1000 Vrms at Sea Level
Mechanical
Durablity:
25 acuations
Normal Force:
150 grams average per contact
Environmental
Temperature Rating Operating:
0擄C to +105擄C
UL File No.: E68080
3M Electronic Handling and Protection Division
6801 River Place Blvd.
Austin, TX 78726-9000
For technical, sales or ordering information call
800-328-0411
or visit our website:
http://www.3M.com/ehpd
