'$7$ 6+((7

6,/,&21 75$16,6725

6'

131 6,/,&21 (3,7$;,$/ 75$16,6725

)25 /2:)5(48(1&< 32:(5 $03/,),(56

The 2SD2230 is an element realizing ultra low V

CE(sat)

. This

transistor is ideal for muting such as stereo recorders, VCRs,

and TVs.

PACKAGE DRAWING (UNIT: mm)

FEATURES

鈥?Low V

CE(sat)

:

V

CE(sat)1

= 33 mV TYP. @I

C

= 100 mA, I

B

= 10 mA

V

CE(sat)2

= 150 mV TYP. @I

C

= 500 mA, I

B

= 20 mA

鈥?High h

FE

and high current

QUALITY GRADES

鈥?Standard

Please refer to 鈥淨uality Grades on NEC Semiconductor

Devices鈥?(Document No. C11531E) published by NEC

Corporation to know the specification of quality grade on the

devices and its recommended applications.

ABSOLUTE MAXIMUM RATINGS (Ta = 25擄C)

擄

Parameter

Collector to base voltage

Collector to emitter voltage

Emitter to base voltage

Collector current (DC)

Total power dissipation

Junction temperature

Storage temperature

Symbol

V

CBO

V

CEO

V

EBO

I

D(DC)

P

T

T

j

T

stg

Ratings

16

16

5

500

200

150

鈭?5

to +150

Unit

V

V

V

mA

mW

擄C

擄C

Electrode connection

1. Emitter (E)

2. Base (B)

3. Collector (C)

Marking: D46

The information in this document is subject to change without notice. Before using this document, please

confirm that this is the latest version.

Not all devices/types available in every country. Please check with local NEC representative for

availability and additional information.

'RFXPHQW 1R '(-9'6 VW HGLWLRQ

'DWH 3XEOLVKHG $SULO  1 &3.

3ULQWHG LQ -DSDQ

漏

2002

1998
