2SC5874S

Transistors

Medium power transistor (30V,

1.0A)

2SC5874S

!

Features

1) High speed switching.

(Tf : Typ. : 35ns at I

C

= 1.0A)

2) Low saturation voltage, typically

(Typ. : 150mV at I

C

= 1.0A, I

B

= 100mA)

3) Strong discharge power for inductive load and

capacitance load.

4) Complements the 2SA2086S

!

External dimensions

(Unit : mm)

SPT

3.0

(15min.)

4.0

2.0

3min.

0.45

2.5

5.0

0.5

0.45

(1) Emitter

(2) Collector

(3) Base

(1) (2) (3)

Taping specifications

Symbol :

C5874S

!Applications

Small signal low frequency amplifier

High speed switching

!

Structure

NPN Silicon epitaxial planar transistor

!

Packaging specifications

Package

Type

Taping

TP

5000

Code

Basic ordering unit (pieces)

2SC5874S

!

Absolute maximum ratings

(Ta=25擄C)

Parameter

Symbol

V

CBO

V

CEO

V

EBO

DC

I

C

I

CP

P

C

Limits

30

30

6

1.0

2.0

300

150

鈭?5

to 150

Unit

V

V

V

A

A

mW

擄C

擄C

鈭?

鈭?

Collector-base voltage

Collector-emitter voltage

Emitter-base voltage

Collector current

Power dissipation

Junction temperature

Range of storage temperature

鈭?

Pw=10ms

鈭?

Each terminal mounted on a recommended land

Pulsed

Tj

Tstg

1/3
