2SC5761(NESG2030M04) Datasheet

  • 2SC5761(NESG2030M04)

  • Discrete

  • 79.21KB

  • 14頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

DATA SHEET
NPN SILICON GERMANIUM RF TRANSISTOR
2SC5761
NPN SiGe RF TRANSISTOR FOR
LOW NOISE
鈰?/div>
HIGH-GAIN AMPLIFICATION
FLAT-LEAD 4-PIN THIN-TYPE SUPER MINIMOLD
FEATURES
鈥?Ideal for low noise
鈰?/div>
high-gain amplification
NF = 0.9 dB TYP., G
a
= 16.0 dB TYP. @ V
CE
= 2 V, I
C
= 5 mA, f = 2 GHz
鈥?Maximum stable power gain: MSG = 20.0 dB TYP. @ V
CE
= 2 V, I
C
= 20 mA, f = 2 GHz
鈥?SiGe technology (f
T
= 60 GHz, f
max
= 60 GHz)
鈥?Flat-lead 4-pin thin-type super minimold (M04) package
ORDERING INFORMATION
Part Number
2SC5761
2SC5761-T2
Quantity
50 pcs (Non reel)
3 kpcs/reel
Supplying Form
鈥?8 mm wide embossed taping
鈥?Pin 1 (Emitter), Pin 2 (Collector) face the perforation side of the tape
Remark
To order evaluation samples, contact your nearby sales office.
The unit sample quantity is 50 pcs.
ABSOLUTE MAXIMUM RATINGS (T
A
= +25擄C)
擄
Parameter
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current
Total Power Dissipation
Junction Temperature
Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
tot
Note
Ratings
8.0
2.3
1.2
35
80
150
鈭?5
to +150
Unit
V
V
V
mA
mW
擄C
擄C
T
j
T
stg
2
Note
Mounted on 1.08 cm
脳
1.0 mm (t) glass epoxy substrate
THERMAL RESISTANCE
Parameter
Junction to Case Resistance
Symbol
R
th (j-c)
Value
150
Unit
擄C/W
Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices
representative for availability and additional information.
Document No. PU10212EJ01V0DS (1st edition)
(Previous No. P15415EJ1V1DS00)
Date Published January 2003 CP(K)
Printed in Japan
The mark
鈥?/div>
shows major revised points.
漏
NEC Compound Semiconductor Devices 2001, 2003
