DATA SHEET

NPN SILICON RF TRANSISTOR

2SC5741

NPN SILICON RF TRANSISTOR FOR

HIGH-FREQUENCY LOW NOISE

3-PIN ULTRA SUPER MINIMOLD

FEATURES

鈥?Low voltage operation, low phase distortion

鈥?Ideal for OSC applications

鈥?3-pin ultra super minimold package

ORDERING INFORMATION

Part Number

2SC5741

2SC5741-T1

Quantity

50 pcs (Non reel)

3 kpcs/reel

Supplying Form

鈥?8 mm wide embossed taping

鈥?Pin 3 (Collector) face the perforation side of the tape

Remark

To order evaluation samples, contact your nearby sales office.

The unit sample quantity is 50 pcs.

ABSOLUTE MAXIMUM RATINGS (T

A

= +25擄C)

擄

Parameter

Collector to Base Voltage

Collector to Emitter Voltage

Emitter to Base Voltage

Collector Current

Total Power Dissipation

Junction Temperature

Storage Temperature

Symbol

V

CBO

V

CEO

V

EBO

I

C

P

tot

Note

Ratings

15.0

5.0

3.0

100

200

150

鈭?5

to +150

Unit

V

V

V

mA

mW

擄C

擄C

T

j

T

stg

2

Note

Mounted on 1.08 cm

脳

1.0 mm (t) glass epoxy PCB

Because this product uses high-frequency technology, avoid excessive static electricity, etc.

The information in this document is subject to change without notice. Before using this document, please confirm that

this is the latest version.

Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices

representative for availability and additional information.

Document No. PU10005EJ01V0DS (1st edition)

Date Published October 2001 CP(K)

Printed in Japan

漏

NEC Compound Semiconductor Devices 2001
