2SC5730K

Transistors

Medium power transistor (30V,

1A)

2SC5730K

Features

1) High speed switching.

(Tf : Typ. : 50ns at I

C

= 1.0A)

2) Low saturation voltage, typically

(Typ. : 150mV at I

C

= 500mA, I

B

= 50mA)

3) Strong discharge power for inductive load and

capacitance load.

4) Complements the 2SA2048K

External dimensions

(Unit : mm)

SMT3

(SC-59)

<SOT-346>

0.4

(3)

(2)

(1)

0.95 0.95

1.9

1.1

1.6

2.8

0.15

(1) Emitter

(2) Base

(3) Collector

0.3Min.

Each lead has same dimensions

Abbreviated symbol :

UM

Applications

Small signal low frequency amplifier

High speed switching

Structure

NPN Silicon epitaxial planar transistor

Packaging specifications

Package

Type

Taping

T146

3000

Code

Basic ordering unit (pieces)

2SC5730K

Absolute maximum ratings

(Ta=25擄C)

Parameter

Symbol

V

CBO

V

CEO

V

EBO

DC

I

C

I

CP

P

C

Limits

30

30

6

1.0

2.0

200

150

鈭?5

to 150

Unit

V

V

V

A

A

mW

擄C

擄C

鈭?

鈭?

Collector-base voltage

Collector-emitter voltage

Emitter-base voltage

Collector current

Power dissipation

Junction temperature

Range of storage temperature

鈭?

Pw=10ms

鈭?

Each terminal mounted on a recommended land

Pulsed

Tj

Tstg

0.8

2.9

1/3

next
