2SC5057
Silicon NPN Triple Diffused Planar
Application
HDTV horizontal deflection output
TO鈥?PL
Features
鈥?High breakdown voltage
V
CBO
= 1700 V
1
2
1. Base
2. Collector
3. Emitter
3
Absolute Maximum Ratings
(Ta = 25擄C)
Item
Collector to base voltage
Collector to emitter voltage
Emitter to base voltage
Collector current
Collector surge current
Collector power dissipation
Junction temperature
Storage temperature
Note: 1. Value at Tc = 25擄C
Symbol
V
CBO
V
CEO
V
EBO
I
C
ic(surge)
P
C
*
1
T
j
Tstg
Ratings
1700
900
6
20
25
200
150
鈥?5 to +150
Unit
V
V
V
A
A
W
擄C
擄C
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
鈥斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€斺€?/div>
next
