Ordering number:EN4692
NPN Epitaxial Planar Silicon Transistor
2SC4660
High-Definition CRT Display
Video Output Driver Applications
Features
路 High f
T
(f
T
=2.2GHz typ)
路 Large current (I
C
=300mA)
路 Adoption of FBET process.
Package Dimensions
unit:mm
2042B
8.0
1.0
4.0
1.0
[2SC4660]
1.4
3.3
3.0
1.6
0.8
1.5
3.0
0.8
0.75
7.5
15.5
11.0
0.7
1 : Emitter
2 : Collector
3 : Base
SANYO : TO-126ML
Specifications
Absolute Maximum Ratings
at Ta = 25藲C
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current (Pulse)
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
ICP
PC
Tc=25藲C
4.8
Conditions
1.7
2.4
Ratings
30
20
3
300
600
1.3
5
150
鈥?5 to +150
Unit
V
V
V
mA
mA
W
W
藲C
藲C
Tj
Tstg
Electrical Characteristics
at Ta = 25藲C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Symbol
ICBO
IEBO
hFE1
hFE2
fT
VCB=20V, IE=0
VEB=2V, IC=0
VCE=5V, IC=50mA
VCE=5V, IC=300mA
VCE=5V, IC=50mA
40
20
2.2
GHz
Conditions
Ratings
min
typ
max
0.1
5.0
200
Unit
碌A(chǔ)
碌A(chǔ)
* : The 2SC4660 is classified by 50mA h
FE
as follows :
40
C
80
60
D
120
100
E
200
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
12099HA (KT)/90794MT (KOTO) BX-0553 No.4692鈥?/3
