Ordering number:EN3581
PNP/NPN Epitaxial Planar Silicon Transistors
2SA1787/2SC4650
High-Definition CRT Display
Video Output Applications
Features
路 High breakdown voltage : V
CEO
鈮?00V.
路 Small reverse transfer capacitance and excellent high
frequency characteristic:
C
re
=1.2pF (NPN), 1.7pF (PNP).
路 Adoption of FBET processes.
Package Dimensions
unit:mm
2064
[2SA1787/2SC4650]
E : Emitter
C : Collector
( ) : 2SA1786
B : Base
SANYO : NMP
Specifications
Absolute Maximum Ratings
at Ta = 25藲C
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Colletor Current (Pulse)
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
ICP
PC
Tj
Tstg
Conditions
Ratings
(鈥?200
(鈥?200
(鈥?5
(鈥?100
(鈥?200
1.0
150
鈥?5 to +150
Unit
V
V
V
mA
mA
W
藲C
藲C
Electrical Characteristics
at Ta = 25藲C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Output Capacitance
Reverse Transfer Capacitance
Collector-to-Emitter Saturation Voltage
Base-to-Emitter Saturation Voltage
Symbol
ICBO
IEBO
hFE
fT
Cob
Cre
VCE(sat)
VBE(sat)
VCB=(鈥?150V, IE=0
VEB=(鈥?4V, IC=0
VCE=(鈥?10V, IC=(鈥?10mA
VCE=(鈥?30V, IC=(鈥?10mA
VCB=(鈥?30V, f=1MHz
VCB=(鈥?30V, f=1MHz
IC=(鈥?20mA, IB=(鈥?2mA
IC=(鈥?20mA, IB=(鈥?2mA
60
150
(2.6)
1.7
(1.7)
1.2
(鈥?0.6
(鈥?1.0
Conditions
Ratings
min
typ
max
(鈥?0.1
(鈥?0.1
320
MHz
pF
pF
pF
pF
V
V
Unit
碌A(chǔ)
碌A(chǔ)
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
83198HA (KT)/5180TA (KOTO) No.3581鈥?/5
