2SB688
AUDIO POWER AMPLIFIER
DC TO DC CONVERTER
PNP
PLANAR SILICON TRANSISTOR
SC-65
!
!
!
High Current Capability
High Power Dissipation
Complementary to 2SD718
ABSOLUTE MAXIMUM RATING (T
a
=25擄C)
C
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base voltage
Collector Current (DC)
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
PC
Tj
Tstg
Rating
-160
-120
-6
-8
80
150
-55~150
Unit
V
V
V
A
W
擄C
擄C
ELECTRICAL CHARACTERISTICS (Ta=25擄C)
C
Characterristic
Collector Base Breakdown Voltage
Collector Emitter Breakdown Voltage
Emitter Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
*DC Current Gain
DC Current Gain
Collector- Emitter Saturation Voltage
Symbol
BVCBO
BVCEO
BVEBO
ICBO
IEBO
hFE1
hFE2
VCE(sat)
Test Condition
IC=-5 mA IE=0
IC=-10 mA
RBE=鈭?/div>
IE=-5mA IC=0
VCB=-60V IE=0
VEB=-4V IC=0
VCE=-5V IC=-1A
VCE=-5V IC=-3A
IB=-0.3A
Min
-160
-120
-6
Typ
Max
Unit
V
V
V
mA
mA
55
50
-0.1
-0.1
160
-1.5
V
