鈥?/div>
Adoption of MBIT processes.
Large current capacitance.
Low collector-to-emitter saturation voltage.
High-speed switching.
Specifications
Absolute Maximum Ratings
at Ta=25擄C
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current (Pulse)
Base Current
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
VCBO
VCEO
VEBO
IC
ICP
IB
PC
Tj
Tstg
Tc=25擄C
Conditions
Ratings
--50
--50
--6
--15
--20
--3
1
20
150
--55 to +150
Unit
V
V
V
A
A
A
W
W
擄C
擄C
Electrical Characteristics
at Ta=25擄C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Output Capacitance
Symbol
ICBO
IEBO
hFE1
hFE2
fT
Cob
Conditions
VCB=-
-40V, IE=0A
VEB=-
-4V, IC=0A
VCE=-
-2V, IC=--330mA
VCE=-
-2V, IC=--10A
VCE=-
-10V, IC=--700mA
VCB=-
-10V, f=1MHz
200
50
120
140
MHz
pF
Ratings
min
typ
max
--10
--10
500
Unit
碌A
碌A
