2N5681
2N5682
MECHANICAL DATA
Dimensions in mm (inches)
NPN SILICON
TRANSISTORS
8 .8 9 (0 .3 5 )
9 .4 0 (0 .3 7 )
7 .7 5 (0 .3 0 5 )
8 .5 1 (0 .3 3 5 )
5 .0 8 (0 .2 0 0 )
ty p .
6 .1 0 (0 .2 4 0 )
6 .6 0 (0 .2 6 0 )
0 .6 6 (0 .0 2 6 )
1 .1 4 (0 .0 4 5 )
0 .8 9 m a x .
(0 .0 3 5 )
0.41 (0.016)
0.53 (0.021)
d ia .
0 .7 1 (0 .0 2 8 )
0 .8 6 (0 .0 3 4 )
!
2 .5 4
(0 .1 0 0 )
1 2 .7 0
(0 .5 0 0 )
m in .
4 5 擄
DESCRIPTION
The 2N5681 and 2N5682 are silicon
expitaxial planar NPN transistors in
jedec TO-39 metal case intended for
use as drivers for high power transis-
tors in general purpose, amplifier and
switching circuits
The complementary PNP types are the
2N5679 and 2N5680 respectively
TO-39
Pin 1 鈥?Emitter
Pin 2 鈥?Base
Pin 3 鈥?Collector
ABSOLUTE MAXIMUM RATINGS
T
CASE
= 25擄c unless otherwise stated
V
CBO
V
CEO
V
EBO
I
C
I
B
P
tot
T
stg
T
j
Collector 鈥?Base Voltage(I
E
= 0)
Collector 鈥?Emitter Voltage (I
B
= 0)
Emitter 鈥?Base Voltage (I
C
= 0)
Continuous Collector Current
Base Current
Total Dissipation at T
case
攏
25擄C
T
amb
攏
25擄C
Operating and Storage Temperature Range
Junction temperature
2N5681
100V
100V
4V
1A
0.5A
10W
1W
2N5682
120V
120V
鈥?5 to +200擄C
200擄C
Semelab plc.
Telephone +44(0)1455 556565. Fax +44(0)1455 552612.
E-mail:
sales@semelab.co.uk
Website:
http://www.semelab.co.uk
Prelim.3/00
