LAB
MECHANICAL DATA
Dimensions in mm
SEME
2N3741 SMD
MEDIUM POWER PNP
SILICON POWER TRANSISTOR
0 .8 9
(0 .0 3 5 )
m in .
3 .7 0 (0 .1 4 6 )
3 .7 0 (0 .1 4 6 )
3 .4 1 (0 .1 3 4 )
3 .4 1 (0 .1 3 4 )
4 .1 4 (0 .1 6 3 )
3 .8 4 (0 .1 5 1 )
3 .6 0 (0 .1 4 2 )
M a x .
鈥?LOW SATURATION VOLTAGE
鈥?HIGH GAIN
1
3
0 .7 6
(0 .0 3 0 )
m in .
1 6 .0 2 (0 .6 3 1 )
1 5 .7 3 (0 .6 1 9 )
FEATURES
鈥?Hermetically sealed Surface Mount
Package.
鈥?Small Footprint - efficient use of PCB
space.
鈥?Lightweight
1 0 .6 9 (0 .4 2 1 )
1 0 .3 9 (0 .4 0 9 )
2
9 .6
9 .3
1 1 .5
1 1 .2
7 (0
8 (0
8 (0
8 (0
.3 8
.3 6
.4 5
.4 4
1 )
9 )
6 )
4 )
0 .5 0 (0 .0 2 0 )
0 .2 6 (0 .0 1 0 )
鈥?High Packing Densities
SMD1
Pad 1 鈥?Base
Pad 2 鈥?Collector
Pad 3 鈥?Emitter
Complementary to NPN
2N3766SMD
ABSOLUTE MAXIMUM RATINGS
(T
case
= 25擄C unless otherwise stated)
V
CBO
V
CEO
V
EBO
I
C
I
C(PK)
I
B
P
tot
T
stg
Collector 鈥?Base Voltage
Collector 鈥?Emitter Voltage (I
B
= 0)
Emitter 鈥?Base Voltage (I
C
= 0)
Collector Current
Peak Collector Current
Base Current
Total Dissipation at T
case
= 25擄C
Operating and Storage Temperature Range
80V
80V
7V
4A
10A
2A
50W
鈥?5 to 200擄C
Semelab Plc reserves the right to change test conditions, parameter limits and package dimensions without notice. Information furnished by Semelab is believed
to be both accurate and reliable at the time of going to press. However Semelab assumes no responsibility for any errors or omissions discovered in its use.
Semelab encourages customers to verify that datasheets are current before placing orders.
Semelab plc.
Telephone +44(0)1455 556565. Fax +44(0)1455 552612.
E-mail:
sales@semelab.co.uk
Website:
http://www.semelab.co.uk
Document Number 2659
Issue 1
1
2
