ISDN MAGNETICS

Dual S Interface Transformer

TM00201

鈥?/div>

Consists of two identical transformer assemblies

mounted in a molded 16-pin DIP terminal header

UL and CSA approved

鈥?/div>

Minimum interwinding breakdown voltage of 2400 Vrms

Qualified per Bellcore TR-TSY-000357-1

鈥?/div>

ELECTRICAL SPECIFICATIONS at 25擄 C

DCR

鈩?/div>

max

Part Number

Turns Ratio

鹵 2%

Primary

Inductance

mH min

Leakage

Inductance

碌

H max

Pri

Interwinding

Capacitance

pF max

Sec

Distributed

Parallel

Capacitance

pF max

2768A

1 : 2.5

22.0

4.0

2.3

5.8

100

SCHEMATIC

2768A

Compatible Transceiver ICs

IC Mfr

IC Part Number

T7234

T7250C

T7254

T7256

T7259

Lucent

Primary

Secondary

漏2000 Bel Fuse Inc. Specifications subject to change without notice. 05.00

Bel Fuse Inc.

198 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com

T2-3
