HIGH FREQUENCY MAGNETICS

T1/E1 Through Hole Hardened Transformer

TM00127

鈥?/div>

Designed to operate at the DS1 rate of 1.544 Mbits/s

Winding (4-6) can handle a 6 A current surge for 1

second with no damage

Operating temperature range: -40擄C to +85擄 C

鈥?/div>

Meets IEC 695, 2-2 flammability requirements

PWB Process Capability: standard printed wiring board

assembly techniques, total-immersion cleaning

Reliability testing: Shock, vibration, temperature cycling,

temperature - humidity - bias

鈥?/div>

ELECTRICAL SPECIFICATIONS AT 25擄 C

Nominal

Turns Ratio

鹵 2%

(3-1):(4-6)

2745AL2

1 : 1.14 CT

Inductance

mH Min

(3-1)

1.25

(3-1)

0.85

DCR

鈩?/div>

max

(4-6)

0.40

Leakage

Inductance

碌H max

(3-1)

1.8

Interwinding

Capacitance

pF max

(3-1) to (4-6)

Minimum

Interwinding

Breakdown

Voltage

Vrms

1000

Part Number

1. measured at 10 kHz, 0.1 Vac

SCHEMATIC

2745AL2

5 CT

1 : 1.14 CT

漏2000 Bel Fuse Inc. Specifications subject to change without notice. 09.00

Bel Fuse Inc.

198 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com

T1-61
