HIGH FREQUENCY MAGNETICS

T1/E1 Through Hole Transformer

TM00120

鈥?/div>

Operates at 1.544 Mbits/s as a line interface

transformer

Provides high step-up ratio

Operating temperature range: -40擄 C to +85擄 C

鈥?/div>

Meets IEC 695, 2-2 flammability requirements

PWB Process Capability: standard printed wiring board

assembly techniques, total-immersion cleaning

Reliability testing: Shock, vibration, temperature cycling,

temperature - humidity - bias

鈥?/div>

ELECTRICAL SPECIFICATIONS AT 25擄 C

Open-circuit

Inductance

碌H Min

(4-6)

430

(4-6)

0.35

DCR

鈩?/div>

max

(3-1)

1.45

Leakage

Inductance

碌H max

(4-6)

0.64

Interwinding

Capacitance

pF max

(4-6) to (3-1)

Minimum

Interwinding

Breakdown

Voltage

Vrms

850

Part Number

Turns Ratio

鹵2%

(4-6):(3-1)

2745AH

1 : 3.76 CT

1. measured at 10 kHz, 0.1 Vac

SCHEMATIC

2745AH

2 CT

1 : 3.76 CT

漏2000 Bel Fuse Inc. Specifications subject to change without notice. 09.00

Bel Fuse Inc.

198 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com

T1-45
