TM00119
PWB Process Capability: Standard Printed Wiring Board
assembly techniques, total-immersion cleaning
Reliability testing: Shock, vibration, temperature cycling,
temperature - humidity - bias
鈥?/div>
鈥?/div>
鈥?/div>
ELECTRICAL SPECIFICATIONS AT 25擄 C
Turns Ratio
鹵2%
Part Number
(3-1):(4-6)
2745AG2
1:1CT
(3-1)
2.3
(3-1)
0.98
Inductance
1
mH Min
DCR
鈩?/div>
max
(4-6)
1.18
Leakage
Inductance
碌H max
(3-1)
2.0
Interwinding
Capacitance
pF max
(3-1) to (4-6)
25
Minimum
Interwinding
Breakdown
Voltage
Vrms
500
1. measured 10 kHz, 0.05 Vac
SCHEMATIC
2745AG2
3
4
5 CT
1
1 : 1 CT
6
漏2000 Bel Fuse Inc. Specifications subject to change without notice. 09.00
Bel Fuse Inc.
198 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
T1-43
