Operating temperature range: -40擄 C to +85擄 C
Meets IEC 695, 2-2 flammability requirements
PWB Process Capability: standard printed wiring board
assembly techniques, total-immersion cleaning
Reliability testing: shock, vibration, temperature cycling,
temperature - humidity - bias
TM00126
鈥?/div>
鈥?/div>
鈥?/div>
ELECTRICAL SPECIFICATIONS AT 25擄 C
DCR
鈩?/div>
max
Leakage
Inductance
2
碌H max
Interwinding
Capacitance
pF max
Turns Ratio
鹵2%
Part Number
(6-7) : (4-1)
3
Inductance
1
mH Min
(6-7)
(6-7)
(4-1)
3
(6-7)
between
(6-7) and (4-2)(3-1)
Minimum
Interwinding
Breakdown
Voltage
Vrms
2741F2
1 : 1 CT
1.1
0.72
0.45
3.5
18
850
1. measured at 10 Hz, 0.1 Vac
2. measured at 100 kHz, 0.1 Vac
3. connect 2 & 3
SCHEMATIC
2741F2
6
4
2
CT
3
7
1:1
1
漏2000 Bel Fuse Inc. Specifications subject to change without notice. 09.00
Bel Fuse Inc.
198 Van Vorst Street, Jersey City, NJ 07302 鈥?Tel 201-432-0463 鈥?Fax 201-432-9542 鈥?www.belfuse.com
T1-59
