AMD-K6

鈩?/div>

High-Performance, AMD-K6

Embedded Processor

DISTINCTIVE CHARACTERISTICS

Advanced 6-Issue RISC86

廬

Superscalar

Microarchitecture

鈥?Seven parallel specialized execution units

鈥?Multiple sophisticated x86-to-RISC86

廬

instruction decoders

鈥?Advanced two-level branch prediction

鈥?Speculative execution

鈥?Out-of-order execution

鈥?Register renaming and data forwarding

鈥?Issues up to six RISC86 instructions per clock

High-Performance IEEE 754-Compatible and

854-Compatible Floating-Point Unit

High-Performance Industry-Standard MMX鈩?/div>

Instructions

Large On-Chip Split 64-Kbyte Level-One (L1)

Cache

鈥?32-Kbyte instruction cache with additional

predecode cache

鈥?32-Kbyte writeback dual-ported data cache

鈥?MESI protocol support

321-Pin Ceramic PGA (Socket 7 Compatible)

Package

Industry-Standard System Management Mode

(SMM)

IEEE 1149.1 Boundary Scan

x86 Binary Software Compatibility

0.25-Micron Process Technology

GENERAL DESCRIPTION

Note:

This data sheet provides information specific to

the AMD-K6E processor. For more information about

the AMD-K6E processor, see the Model 7 section of

the

AMD-K6 Processor Data Sheet

, order #20695.

With the AMD-K6E embedded processor, AMD

continues to deliver leading-edge processor solutions.

Based on the highly successful AMD-K6 processor

with 0.25-micron process technology, the AMD-K6E

processor delivers high performance with a low core

voltage and low power dissipation. This new,

embedded version of the AMD-K6 processor continues

to leverage today鈥檚 cost-effective infrastructure to

deliver a superior price/performance solution.

As a member of AMD鈥檚 E86鈩?family of embedded x86-

based processors, the AMD-K6E processor extends

the range of software-compatible performance

allowing existing x86 designs and software to be used

in high-performance products. In addition to a wide

selection of inexpensive development tools, compilers,

debuggers, chip sets, and PC operating systems, the

AMD-K6E processor is also supported by a number of

real-time operating systems (RTOS) such as QNX,

pSOS, RTXC, and Windows

廬

CE. This compatibility

and support result in decreased development costs

and improved time to market.

Publication#

22459

Rev:

Amendment/0

Issue Date:

January 1999
