220CNQ030 Datasheet

  • 220CNQ030

  • 30V 200A Schottky Common Cathode Diode in a TO-244AB Non-Iso...

  • 146.66KB

  • 5頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Bulletin PD-2.280 rev. C 07/01
220CNQ030
SCHOTTKY RECTIFIER
220 Amp
TO-244AB
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular
waveform
V
RRM
range
I
FSM
@ tp = 5 碌s sine
V
F
T
J
@ 110Apk, T
J
=125擄C
(per leg)
range
Description/Features
The 220CNQ center tap Schottky rectifier module series has
been optimized for low reverse leakage at high temperature.
The proprietary barrier technology allows for reliable opera-
tion up to 150 擄C junction temperature. Typical applications
are in high current switching power supplies, plating power
supplies, UPS systems, converters, free-wheeling diodes,
welding, and reverse battery protection.
150 擄C T
J
operation
Center tap module
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
220CNQ... Units
220
30
22,500
0.40
- 55 to 150
A
V
A
V
擄C
80.01 [3.150]
40.26 [1.585]
39.75 [1.565]
COMMON
CATHODE
脴
10.41 [.410]
9.65 [.380]
20.32 [.800]
17.78 [.700]
LUG
TERMINAL
ANODE 1
LUG
TERMINAL
ANODE 2
2X 脴
7.49 [.295]
6.99 [.275]
34.925 [1.375]
REF.
63.50 [2.500]
60.96 [2.400]
脴
4.95 [.195]
4.70 [.185]
1/4-20 SLOTTED HEX
BASE
COMMON CATHODE
23.55 [.927]
20.42 [.804]
15.75 [.620]
14.99 [.590]
3.35 [.132]
3.02 [.119]
92.71 [3.650]
90.17 [3.550]
NOTES:
1. DIMENSIONS ARE SHOWN IN MILLIMETERS [INCHES].
2. CONTROLLING DIMENSION: MILLIMETER
Modified JEDEC
Outline TO-244AB
Dimensions in millimeters and (inches)
www.irf.com
1

220CNQ030 產品屬性

  • 30

  • 半導體模塊

  • 二極管，整流器

  • -

  • 570mV @ 220A

  • 10mA @ 30V

  • 220A

  • 30V

  • -

  • 肖特基

  • 快速恢復 = 200mA（Io）

  • 1 對共陰極

  • 底座安裝

  • TO-244AB

  • TO-244AB

  • 散裝

  • *220CNQ030
