response to process changes.
3-wire RTD and linear inputs.
The patented Instant Accuracy鈩?/div>
feature allows precise input
measurement and control to be
achieved from the moment of
start up, independent of warm-up
drift, and even during periods of
ambient temperature upset.
Precise Control
Advanced PID or valve
positioning algorithms give
stable straight-line control of
the process. A power feedback
feature automatically
compensates the output to
stabilize the temperature of
electrically heated loads during
supply voltage fluctuations.
Proprietary cooling algorithms
ensure optimum control of fan,
oil and water-cooled systems.
Velocity mode valve control
algorithms allow precise valve
Easy Operation
Bright, clear front-panel LED鈥檚
display the process variable and
a configurable lower display for
setpoint or other important
parameters. Tactile pushbuttons
ensure positive operation. All
instrument parameters are easy
to access and may be presented
to the operator or hidden from
view under password protection.
2208e
Temperature
Controller
UL and cUL pending
A Siebe Group Company
1
2
3
4
