Moeller NK2528-1024GB
3
Description
easy control relay
SIMPLY easy 鈥?Clever switching and controlling
easy is a compact, user-friendly control relay for simple control applications. Appli-
cations range from building and domestic automation to machine and plant con-
trol.
easy has built-in user-friendly operating elements and an LCD display. Just connect
up easy and draw your circuit diagram on the display by pressing the buttons. easy
works with make contacts, break contacts, and relays.
Enter your circuit diagram in easy just like you sketched it on paper. easy has basic
and special functions for relay and contactor controls, and lots more.
You can make changes to your circuit just by pressing the buttons. Time consuming
rewiring is not necessary.
SIMPLY easy 鈥?Applications everywhere
鈥?Building and domestic automation, controllers for lighting, doors, window
shutters...
鈥?Controls for ventilators, rotating doors, greenhouses, exterior lighting, window
controllers, shop display lighting control...
鈥?Controls for temperature, ventilation and brightness levels...
鈥?Controls for machines and plant, presses, conveyor belts, oscillating conveyors,
sorters, pumps...
SIMPLY easy 鈥?Open for change
The easy circuit diagram can be entered and modified just by pressing the buttons.
SIMPLY easy 鈥?Everything built in
(some features depend on the type)
鈥?An LCD display for showing the circuit diagram
鈥?Operation buttons for wiring, value entry or switching
鈥?4 relay outputs with max. 10 A output current or 0.5 A transistor outputs up to
2 A, suitable for parallel connection
鈥?Circuit diagrams can be created with make contacts, break contacts, relays,
series and parallel circuits
鈥?Voltage supply (24 V DC or 115/230 V AC)
鈥?8/12 digital inputs, expandable to 24 digital inputs
(115/230 V AC or 24 V DC)
鈥?2 analog inputs (DC models only, two digital inputs can also be used for analog
signals)
鈥?Non-volatile circuit diagram and parameter memory (EEPROM)
(retentive data) (EEPROM)
鈥?Display of message texts, setpoint and actual values for timers, counters, time
and analog values
鈥?Socket for external memory card or PC interface cable
鈥?Time switch with time and weekday(s)
鈥?DST setting (summer time/winter time change)
鈥?Protect your circuit diagram and settings against unauthorized changes with a
password to protect your know-how
鈥?Optional debounce (input delay) function (reliable switching with fast signals)
鈥?Selectable menu languages, 5 and 10 languages (D, GB, F, I, E, for EASY600 also
P, NL, S, PL,TR)
鈥?4 cursor buttons can also be used as input contacts in the easy circuit diagra
(built in manual operation mode)
鈥?Local or remote expansion of inputs and outputs.
Remote expansion by means of two wire cable up to 30 m between basic unit
and expansion unit
鈥?Large ambient temperature range from 鈥?5 擄C to +55 擄C
S1
K1
S4
S6
S5
T1
T1
K1
K2
T1
easy Control Relay
1
2
3
4
5
6
7
8
9
10
11
