Air Dielectric Directional Couplers
Low Loss, Octave Bandwidth
Features
q
q
q
q
2023 Series
V2.00
Air Dielectric for Low Loss
Frequency Range: 1.0 to 18 GHz
Octave Bandwidths
Meets MIL-E-5400 and MIL-E-16400 Environments
Description
These directional couplers feature compact packaging
and four-port construction. This combination permits
鏗俥xibility in system designs. They are intended for test
and measurement setups as well as for system use.
Temperature range is -54擄 to +110擄C. These units incor-
porate three miniature, low VSWR SMA jack connectors.
Isolated port is terminated with 1/2 watt, 50 ohm load.
Mechanical Speci鏗乧ations
Case
Style
1
2
3
4
5
A
Inch (mm)
2.55 (64.8)
1.69 (42.7)
1.41 (35.6)
1.19 (30.0)
1.08 (27.4)
B
Inch (mm)
2.39 (60.8)
1.52 (38.7)
1.24 (31.5)
1.02 (26.0)
0.92 (23.4)
C
Inch (mm)
1.97 (50.1)
1.11 (28.2)
0.82 (20.8)
0.60 (15.2)
0.50 (12.7)
D
Inch (mm)
1.16 (29.4)
1.16 (29.4)
1.16 (29.4)
1.16 (29.4)
1.28 (32.6)
E
F
Inch (mm) Inch (mm)
0.50 (12.7)
0.50 (12.7)
0.50 (12.7)
0.50 (12.7)
0.63 (15.9)
0.38 (9.7)
0.38 (9.7)
0.38 (9.7)
0.38 (9.7)
0.38 (9.7)
G
Inch (mm)
0.91 (23.2)
0.91 (23.2)
0.91 (23.2)
0.91 (23.2)
0.97 (24.6)
H
Inch (mm)
Weight
oz.
g
54
31
31
28
30
0.093 (2.36) 1.90
0.093 (2.36) 1.10
0.093 (2.36) 1.07
0.093 (2.36) 0.98
0.093 (2.36) 1.01
M/A-COM Division of AMP Incorporated
s
North America: Tel. (800) 366-2266, Fax (800) 618-8883
s
Asia/Paci鏗乧: Tel. +85 2 2111 8088, Fax +85 2 2111 8087
s
Europe: Tel. +44 (1344) 869 595, Fax +44 (1344) 300 020
www.macom.com
AMP and Connecting at a Higher Level are trademarks.
Speci鏗乧ations subject to change without notice.
