Philips Components
Product speci鏗乧ation
Fusible chip resistor
size 1206
FEATURES
鈥?/div>
Overload protection without the risk
of fire
鈥?/div>
Grey coating for ease of recognition
鈥?/div>
Reduced size of final equipment
鈥?/div>
Low assembly costs
鈥?/div>
Higher component and equipment
reliability.
APPLICATIONS
鈥?/div>
Power supplies in small sized
equipment
鈥?/div>
Car telephones
鈥?/div>
Portable radio, CD and cassette
players.
DESCRIPTION
The resistors are constructed on a
high grade ceramic body (aluminium
oxide). Internal metal electrodes are
added at each end and connected by
a resistive paste which is applied to
the top surface of the substrate. The
composition of the paste is adjusted
to give the approximate resistance
required and the value is trimmed to
within tolerance, by laser cutting of
this resistive layer.
The resistive layer is covered with a
protective coat and printed with the
resistance value. Finally, the two
external end terminations are added.
For ease of soldering the outer layer
of these end terminations is a lead/tin
alloy.
To enable recognition of a fusible
device, the resistor should be
mounted face up.
QUICK REFERENCE DATA
DESCRIPTION
Resistance range
Resistance tolerance
Temperature coef鏗乧ient:
1 to 4.7
鈩?/div>
5.1 to 510
鈩?/div>
Absolute maximum dissipation at
T
amb
= 70
擄C
Maximum permissible voltage
Operating temperature range
Climatic category (IEC 60068)
Basic speci鏗乧ation
ORDERING INFORMATION
Table 1
Ordering code indicating type and packaging
鈮ぢ?50 脳
10
鈭?
/K
鈮ぢ?00 脳
10
鈭?
/K
0.125 W
鹵5%
FRC01
5%
VALUE
1 to 510
鈩?
E24/E96 series
200 V (DC or RMS)
鈭?5 擄C
to +125
擄C
55/125/56
IEC 60115-8
ORDERING CODE 2322 750 .....
TYPE
PAPER TAPE ON REEL
5000 units
FRC01
Ordering code (12NC)
鈥?/div>
The resistors have a 12-digit
ordering code starting with 2322
鈥?/div>
The subsequent 4 digits indicate
the resistor type and packaging;
see Table 1.
鈥?/div>
The remaining 4 digits indicate the
resistance value:
鈥?The first 3 digits indicate the
resistance value.
鈥?The last digit indicates the
resistance decade in
accordance with Table 2.
Table 2
6....
Last digit of 12NC
LAST DIGIT
8
9
1
RESISTANCE
DECADE
1 to 9.76
鈩?/div>
10 to 97.6
鈩?/div>
100 to 240
鈩?/div>
O
RDERING EXAMPLE
The ordering code of a FRC01
resistor, value 200
鈩?
packed in
paper tape and supplied on a reel of
5000 units is: 2322 750 62001.
1999 Feb 10
361
