2.22238E+11 Datasheet

  • 2.22238E+11

  • KONDENSATOR POLYPRO RADIAL 220NF 1000V

  • 34頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BC Components
Product speci鏗乧ation
AC and pulse
metallized polypropylene 鏗乴m capacitors
MKP/MKP RADIAL POTTED TYPE
MKP/MKP 378
PITCH 15/22.5/27.5 mm
handbook, full pagewidth
P = 15 mm
P = 22.5 to 27.5 mm
CBA216
Fig.1 Simplified outlines.
FEATURES
鈥?/div>
15 to 27.5 mm lead pitch
鈥?/div>
Low contact resistance
鈥?/div>
Low loss dielectric
鈥?/div>
Small dimensions for high density
packaging
鈥?/div>
Supplied loose in box and taped on
reel.
APPLICATIONS
(1)
鈥?/div>
Where steep pulses occur e.g.
SMPS (switch mode power
supplies)
鈥?/div>
Motor control circuits
鈥?/div>
S-correction.
DETAIL SPECIFICATION
For more detailed data and test
requirements see
鈥淭ype detail
specification HQN-384-17/102鈥?
QUICK REFERENCE DATA
DESCRIPTION
Capacitance range (E24 series)
Capacitance tolerance
Rated (DC) voltage
values available on request
Rated (AC) voltage
values available on request
Rated peak-to-peak voltage
values available on request
Climatic category
Rated temperature (DC)
Rated temperature (AC)
Maximum application
temperature
Reference speci鏗乧ation
Performance grade
Stability grade:
pitch 15 mm
pitch 22.5 and 27.5 mm
VALUE
0.001 to 0.68
碌F
鹵5%
630 V; 1000 V; 1600 V; 2000 V; 2500 V
3000 V; 4000 V; 5000 V
300 V; 400 V; 500 V; 600 V; 675 V
800 V; 1000 V; 1200 V
850 V; 1130 V; 1400 V; 1700 V; 1900 V
2300 V; 2800 V; 3400 V
55/085/56
85
擄C
70
擄C
85
擄C
IEC 60384-17
grade 1 (long life)
grade 2
grade 1
(1) It is not advised to use these products
as resonance capacitors in 鏗倅-back
applications.
1999 Apr 29
548
