1T1G
THRU
1T7G
1.0 AMP. Glass Passivated Rectifiers
Voltage Range
50 to 1000 Volts
Current
1.0 Ampere
Features
Low forward voltage drop
High current capability
High reliability
High surge current capability
3mm miniature body
TS-1
Mechanical Data
Cases: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Axial leads, solderable per MIL-STD-
202, Method 208 guaranteed
Polarity: Color band denotes cathode end
High temperature soldering guaranteed:
260
o
C/10 seconds/.375鈥?(9.5mm) lead
lengths at 5 lbs., (2.3kg) tension
Weight: 0.20 gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25鈩僡mbient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol
1T1G 1T2G 1T3G 1T4G 1T5G 1T6G 1T7G
Units
Type Number
Maximum Recurrent Peak Reverse Voltage
50 100 200 400 600 800 1000 V
V
RRM
Maximum RMS Voltage
35
70 140 280 420 560 700
V
V
RMS
Maximum DC Blocking Voltage
50 100 200 400 600 800 1000 V
V
DC
Maximum Average Forward Rectified
Current .375 (9.5mm) Lead Length
@T
A
= 50鈩?/div>
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 1.0A
Maximum DC Reverse Current @ T
A
=25鈩?/div>
at Rated DC Blocking Voltage @ T
A
=125鈩?/div>
I
(AV)
I
FSM
V
F
I
R
1.0
30
1.1
1.0
A
A
V
uA
uA
pF
O
C/W
鈩?/div>
鈩?/div>
5.0
100
Typical Junction Capacitance ( Note 1)
Cj
10
Typical Thermal Resistance (Note 2)
R
胃
JA
100
Operating Temperature Range
T
J
-65 to +150
Storage Temperature Range
T
STG
-65 to +150
Notes: 1. Measured at 1 MHz and Applied Reverse Voltage of 4.0 V D.C.
2. Mount on Cu-Pad Size 5mm x 5mm on P.C.B.
- 530 -
