1SMZG06GP..1SMZG10GP

0.8 A Surface Mounted Glass Passivated Bridge

Dimensions in mm.

MBS

Voltage

600 V - 1000V

Current

0.8 A

廬

鈥?Glass passivated junction

鈥?High current

鈥?The plastic material carries

UL recognition 94 V-0

Maximum Ratings, according to IEC publication No. 134

1SMZG06GP

V

RRM

V

RMS

I

F(AV)

I

FSM

T

j

T

st g

Peak recurrent reverse voltage

Maximum RMS voltage

Forward current at Tamb = 25

8.3 ms. peak forward surge

Operating temperature range

Storage temperature

600 V

420 V

0.8 A

30 A

- 40 to + 150 潞C

- 40 to + 150 潞C

1SMZG10GP

1000 V

700 V

Electrical Characteristics at Tamb = 25 潞C

V

F

I

R

Max. forward voltage drop per

element at I

F

= 0.8 A

Max. reverse current per element at V

RRM

1.15 V

10 碌A(chǔ)

Mar - 03
