1SMF16BT1, 1SMF16BT3,
1SMF16BT3G
Zener Transient
Voltage Suppressor
SOD鈭?23 Flat Lead Package
The 1SMF16B is designed to protect voltage sensitive components
from high voltage, high energy transients. Excellent clamping
capability, high surge capability, low Zener impedance and fast
response time. Because of its small size, it is ideal for use in cellular
phones, portable devices, business machines, power supplies and
many other industrial/consumer applications.
Specification Features:
http://onsemi.com
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Stand鈭抩ff Voltage: 16 Volt
Peak Power 鈭?175 Watts @ 1 ms
Maximum Clamp Voltage @ Peak Pulse Current
Low Leakage
Response Time is Typically < 1 ns
IEC61000鈭?鈭? Level 4 ESD Protection
Low Profile 鈭?Maximum Height of 1.0 mm
Small Footprint
Cathode Indicated by Polarity Band
Pb鈭扚ree Package is Available
PLASTIC SURFACE MOUNT
ZENER OVERVOLTAGE
TRANSIENT SUPPRESSOR
175 WATT PEAK POWER
1
1: CATHODE
2: ANODE
2
Mechanical Characteristics:
CASE:
Void-free, transfer-molded, thermosetting plastic
LEAD FINISH:
100% Matte Sn (Tin)
MOUNTING POSITION:
Any
QUALIFIED MAX REFLOW TEMPERATURE:
260擄C
SOD鈭?23FL
CASE 498
PLASTIC
Device Meets MSL 1 Requirements
Epoxy Meets UL 94, V鈭?
MARKING DIAGRAM
1
CATHODE
MLU
D
2
ANODE
MLU
D
= Specific Device Code
= Date Code
ORDERING INFORMATION
Device
1SMF16BT1
1SMF16BT3
1SMF16BT3G
Package
SOD鈭?23FL
SOD鈭?23FL
SOD鈭?23FL
(Pb鈭扚ree)
Shipping
鈥?/div>
3,000/Tape & Reel
10,000/Tape & Reel
10,000/Tape & Reel
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
漏
Semiconductor Components Industries, LLC, 2004
1
February, 2004 鈭?Rev. 1
Publication Order Number:
1SMF16B/D
