1SMB5913BT3 Series

3 Watt Plastic Surface Mount

Zener Voltage Regulators

This complete new line of 3 Watt Zener diodes offers the following

advantages.

Specification Features:

鈥?/div>

Zener Voltage Range 鈥?3.3 V to 200 V

ESD Rating of Class 3 (>16 KV) per Human Body Model

Flat Handling Surface for Accurate Placement

Package Design for Top Side or Bottom Circuit Board Mounting

http://onsemi.com

Mechanical Characteristics:

CASE:

Void-free, transfer-molded plastic

FINISH:

All external surfaces are corrosion resistant and leads are

PLASTIC SURFACE MOUNT

ZENER VOLTAGE

REGULATOR DIODES

3.3鈥?00 VOLTS

3 WATT DC POWER

readily solderable

MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:

260擄C for 10 Seconds

LEADS:

Modified L鈥揃end providing more contact area to bond pads

POLARITY:

Cathode indicated by polarity band

FLAMMABILITY RATING:

UL94 V鈥?

MAXIMUM RATINGS

Rating

Maximum Steady State Power Dissipation

@ T

= 75擄C

Measured at Zero Lead Length

Derate Above 75擄C

Thermal Resistance from Junction to Lead

Maximum Steady State Power Dissipation

@ T

= 25擄C (Note 1.)

Derate Above 25擄C

Thermal Resistance from Junction

to Ambient

Operating and Storage

Temperature Range

Symbol

Value

3.0

Unit

Cathode

Anode

SMB

CASE 403A

PLASTIC

qJL

550

mW/擄C

擄C/W

MARKING DIAGRAM

YWW

9xxB

= Year

= Work Week

= Specific Device Code

(See Table Page 3)

qJA

, T

stg

4.4

226

鈥?5 to

+150

mW/擄C

擄C/W

擄C

1. FR鈥? board, within 1鈥?to device, using ON Semiconductor minimum

recommended footprint, as shown in case 403A outline dimensions spec.

ORDERING INFORMATION

Device

{

1SMB59xxBT3

Package

SMB

Shipping

2500/Tape & Reel

Devices listed in

bold, italic

are ON Semiconductor

Preferred

devices.

Preferred

devices are recommended

choices for future use and best overall value.

鈥燭he 鈥淭3鈥?suffix refers to a 13 inch reel.

漏

Semiconductor Components Industries, LLC, 2001

May, 2001 鈥?Rev. 1

Publication Order Number:

1SMB5913BT3/D
