Working Peak Reverse Voltage Range 鈥?10 V to 78 V
Standard Zener Breakdown Voltage Range 鈥?11.7 V to 91.3 V
Peak Power 鈥?400 Watts @ 1 ms
ESD Rating of Class 3 (> 16 KV) per Human Body Model
Response Time is Typically < 1 ns
Flat Handling Surface for Accurate Placement
Package Design for Top Slide or Bottom Circuit Board Mounting
Low Profile Package
SMA
CASE 403B
PLASTIC
Mechanical Characteristics:
CASE:
Void-free, transfer-molded plastic
FINISH:
All external surfaces are corrosion resistant and leads are
readily solderable
MAXIMUM CASE TEMPERATURE FOR SOLDERING PURPOSES:
MARKING DIAGRAM
260擄C for 10 Seconds
POLARITY:
Cathode polarity notch does not indicate polarity
MOUNTING POSITION:
Any
MAXIMUM RATINGS
Rating
Peak Power Dissipation (Note 1.)
@ T
L
= 25擄C, Pulse Width = 1 ms
DC Power Dissipation @ T
L
= 75擄C
Measured Zero Lead Length (Note 2.)
Derate Above 75擄C
Thermal Resistance from Junction to Lead
DC Power Dissipation (Note 3.) @ T
A
= 25擄C
Derate Above 25擄C
Thermal Resistance from Junction
to Ambient
Operating and Storage
Temperature Range
Symbol
P
PK
P
D
Value
400
1.5
20
50
0.5
4.0
250
鈥?5 to
+150
Unit
W
W
mW/擄C
擄C/W
W
mW/擄C
擄C/W
擄C
xxC
LL
Y
WW
xxC
LLYWW
= Specific Device Code
=
(See Table Next Page)
= Assembly Location
= Year
= Work Week
ORDERING INFORMATION
Device
{
1SMAxxCAT3
Package
SMA
Shipping
5000/Tape & Reel
R
qJL
P
D
R
qJA
T
J
, T
stg
鈥燭he 鈥淭3鈥?suffix refers to a 13 inch reel.
1. 10 X 1000
ms,
non鈥搑epetitive
2. 1鈥?square copper pad, FR鈥? board
3. FR鈥? board, using ON Semiconductor minimum recommended footprint, as
shown in 403B case outline dimensions spec.
*Please see 1SMA5.0AT3 to 1SMA78AT3 for Unidirectional devices.
漏
Semiconductor Components Industries, LLC, 2001
1
May, 2001 鈥?Rev. 4
Publication Order Number:
1SMA10CAT3/D
