1N6674
JAN, JANTX, JANTXV
A Microsemi Company
580 Pleasant St.
Watertown, MA 02172
Phone: 617-924-9280
Fax: 617-924-1235
POWER PRODUCT SPECIFICATION
30 A 500V COMMON CATHODE
DUAL ULTRAFAST RECTIFIER
FEATURES:
n
QUALIFIED PARTS LISTING MIL-PRF-19500/617
n
LOW FORWARD VOLTAGE DROP
n
ISOLATED HERMETICALLY SEALED PACKAGE
n
RUGGED CERAMIC FEEDTHROUGH CONSTRUCTION
Absolute Maximum Ratings:
Symbol
VRWM
VRRM
VR
IO
IFSM
ROJC
ROJA
Tj
Tstg
*1
*1
*1
*1
*1
*1
*1
Parameter
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Forward Current, TC= 100 擄C
Peak Surge Current
Thermal Resistance, Junction to Case
Thermal Resistance, Junction to Ambient
Operating Junction Temperature Range
Storage Temperature Range
Limit
500
500
500
15
150
2.0
40
-65 to +200
-65 to +200
Unit
Vdc
Vdc
Vdc
Adc
A(pk)
擄C/W
擄C/W
擄C
擄C
.545
.535
.685
.665
.800
.790
PHYSICAL DIMENSIONS
.545
.535
.149
.139
D
.570
.510
.150
BSC
.045
.035
D
NOTE 1: EACH INDIVIDUAL DIODE
.050
.040
.150
BSC
.260
.249
Electrical Characteristics (Per Diode) @
25擄C unless otherwise specified
Symbol
Parameter
Conditions
Package Designation: TO-254
PIN # 1: ANODE
PIN # 2: CATHODE
PIN # 3: ANODE
Min
Max
Unit
Vf1
Forward Voltage
If = 10A(pk)
1.35 Vdc
Vf2
Forward Voltage
If = 20A(pk)
1.55 Vdc
IR1
Reverse Current
VR = 400Vdc
50.0 uA
IR2
Reverse Current
VR = 400Vdc TC=100擄 C
5.0 mA
Vf3
Forward Voltage
If = 10A(pk), TA= -65擄C
1.45 Vdc
trr
Reverse Recovery Time
Cond. B, If=.5Adc, IR=1A, IRR=.25A
35
ns
Cj
Junction Capacitance
VR= 10Vdc, f=1MHz
150 pF
Sertech reserves the right to make changes to any product design, specification or other information at any time without prior
notice.
MSC1002.PDF 2/9/99
