HERMETIC CERAMIC PACKAGE
Bv > 60V at 10uA
Ir < 100nA at 40V
C < 8.0 pF
1
4
6
10
12
11
9
8
7
5
3
Absolute Maximum Ratings:
Symbol
VBR(R) *1 *2
IO
*1 * 3
IFSM *1
PT1
*4
PT2
*4
Top
Tstg
Parameter
Reverse Breakdown Voltage
Continuous Forward Current
Peak Surge Current (tp= 1/120 s)
Power Dissipation per Junction @ 25擄C
Power Dissipation per Package @ 25擄C
Operating Junction Temperature Range
Storage Temperature Range
Limit
60
300
500
400
600
-65 to +150
-65 to +200
Unit
Vdc
mAdc
mAdc
mW
mW
擄C
擄C
2
13
14
NOT CONNECTED
.320
.290
.200
.125
.200
MAX
.310
.220
.005
MIN
.023
.014
.070
.030
.785
MAX
.100
BSC
.098
MAX
NOTE 1: Each Diode
NOTE 2: Pulsed: PW = 100ms max.; duty cycle < 20%
NOTE 3: Derate at 2.4mA/擄C above +25 擄C
NOTE 4: Derate at 4.0mW/擄C above +25 擄C
.060
.015
O-15
.015
.008
Electrical Characteristics (Per Diode) @
25擄C unless otherwise specified
Symbol Parameter
Vf1
Vf2
IR1
Ct
tfr
trr
Forward Voltage
Forward Voltage
Reverse Current
Capacitance (pin to pin)
Forward Recovery Time
Reverse Recovery Time
Conditions
PACKAGE OUTLINE
Min
Max
1
1.5
0.1
8.0
40
20
Unit
Vdc
Vdc
uAdc
pF
ns
ns
If = 100mAdc *1
If = 500mAdc *1
VR = 40 Vdc
VR = 0 Vdc ; f = 1 MHz
If = 500mAdc
If = IR = 200mAdc, irr = 20mAdc, RL = 100 ohms
NOTE 1: Pulsed: PW = 300us +/- 50us, duty cycle < 2%, 90us after leading edge
Sertech reserves the right to make changes to any product design, specification or other
information at any time without prior notice.
MSC1019.PDF Rev - 11/25/98
