1N6267A/D Datasheet

  • 1N6267A/D

  • 1500 Watt MOSORB Zener Transient Voltage Suppressors

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

1N6267A Series
1500 Watt Mosorb鈩?Zener
Transient Voltage Suppressors
Unidirectional*
Mosorb devices are designed to protect voltage sensitive
components from high voltage, high鈥揺nergy transients. They have
excellent clamping capability, high surge capability, low zener
impedance and fast response time. These devices are
ON Semiconductor鈥檚 exclusive, cost-effective, highly reliable
Surmetic鈩?axial leaded package and are ideally-suited for use in
communication systems, numerical controls, process controls,
medical equipment, business machines, power supplies and many
other industrial/consumer applications, to protect CMOS, MOS and
Bipolar integrated circuits.
Specification Features:
http://onsemi.com
Cathode
Anode
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Working Peak Reverse Voltage Range 鈥?5.8 V to 214 V
Peak Power 鈥?1500 Watts @ 1 ms
ESD Rating of Class 3 (>16 KV) per Human Body Model
Maximum Clamp Voltage @ Peak Pulse Current
Low Leakage < 5
碌A(chǔ)
Above 10 V
UL 497B for Isolated Loop Circuit Protection
Response Time is Typically < 1 ns
AXIAL LEAD
CASE 41A
PLASTIC
Mechanical Characteristics:
CASE:
Void-free, transfer-molded, thermosetting plastic
FINISH:
All external surfaces are corrosion resistant and leads are
L
1N6
xxxA
1.5KE
xxxA
YYWW
L = Assembly Location
1N6xxxA = JEDEC Device Code
1.5KExxxA = ON Device Code
YY = Year
WW = Work Week
readily solderable
MAXIMUM LEAD TEMPERATURE FOR SOLDERING PURPOSES:
230擄C, 1/16鈥?from the case for 10 seconds
POLARITY:
Cathode indicated by polarity band
MOUNTING POSITION:
Any
MAXIMUM RATINGS
Rating
Peak Power Dissipation (Note 1.)
@ T
L
鈮?/div>
25擄C
Steady State Power Dissipation
@ T
L
鈮?/div>
75擄C, Lead Length = 3/8鈥?/div>
Derated above T
L
= 75擄C
Thermal Resistance, Junction鈥搕o鈥揕ead
Forward Surge Current (Note 2.)
@ T
A
= 25擄C
Operating and Storage
Temperature Range
Symbol
P
PK
P
D
Value
1500
5.0
20
R
qJL
I
FSM
T
J
, T
stg
20
200
鈥?65 to
+175
Unit
ORDERING INFORMATION
Device
1.5KExxxA
Watts
1.5KExxxARL4
Watts
mW/擄C
擄C/W
Amps
擄C
Devices listed in
bold, italic
are ON Semiconductor
Preferred
devices.
Preferred
devices are recommended
choices for future use and best overall value.
Package
Axial Lead
Axial Lead
Axial Lead
Axial Lead
Shipping
500 Units/Box
1500/Tape & Reel
500 Units/Box
1500/Tape & Reel
1N6xxxA
1N6xxxARL4
1. Nonrepetitive current pulse per Figure 5 and derated above T
A
= 25擄C per
Figure 2.
2. 1/2 sine wave (or equivalent square wave), PW = 8.3 ms, duty cycle = 4 pulses
per minute maximum.
*Please see 1.5KE6.8CA to 1.5KE250CA for Bidirectional Devices
漏
Semiconductor Components Industries, LLC, 2001
1
March, 2001 鈥?Rev. 3
Publication Order Number:
1N6267A/D
