Splash oil lubrication
- For better wear resistance.
Cast valve plates
- For durability.
Rust proof stainless steel valves
- For extended life.
Special compression ring
- For longer life.
Trapped reed valves
- Eliminating severe pump damage.
Strip stainless steel valves
- For higher output and durability.
Dynamically balanced crankshaft
- For improved smoothness.
One piece con-rod and piston
- Lightweight and high efficiency.
High performance fan
- With specially designed fan blades for maximum
forced air cooling.
Professional aftercooler
- For better efficiency.
Integral air filter
- To avoid accidental damage.
Larger oil sump
- For better lubrication.
Needs little maintenance
- For added convenience.
Low oil consumption
- Highly efficient
Thermal protection against overheating
- With automatic reset.
Tough cover
- For safety and protection.
High efficiency pump
- For more air.
Powerful 3.0HP motor
- Superb power from domestic supply.
Large 12.0cfm displacement.
Easy to use
- Ideal for home DIY use.
Over 100 service agents nationwide
- For easy servicing.
100% production line tested
- For greater reliability.
Equipped with automatic stop/start control, pressure regulator, gauges and
drain valve
- Added value.
One year warranty
- For peace of mind.
Airmate
01622
Item N潞 01638
Airmate
Cirrus 34025
WHEEL
Thermal
鈼?/div>
Wheel mounted 24 litre receiver
- With safety valve for worry free operation.
Item N潞 01639
Airmate
01638
Cirrus 34050
WHEEL
Thermal
鈼?/div>
Wheel mounted 50 litre receiver
- With safety valve, gives even greater air
storage when required.
Item N潞 01622
Airmate
Cirrus 340100
WHEEL
Thermal
鈼?/div>
Wheel mounted massive 100 litre receiver
- With safety valve, gives even
greater air storage when required.
01639
MODEL
ITEM NO
PISTON DISP L/MIN
.
PISTON DISP CFM
.
F.A.D. L/MIN
F.A.D. CFM
HP
PHASE
R.P
.M
NO. CYLINDERS
NO. STAGES
MAX. PRESSURE BAR
MAX. PRESSURE PSI
RECEIVER CAPACITY LITRES
PACKED DIMENSIONS (HxWxL) MM
WEIGHT KGS
CIRRUS 34025
01638
340
12
213
7.5
3
1 - 13A
2800
1
1
8
118
24
590x275x600
27
CIRRUS 34050
01639
340
12
213
7.5
3
1 -13A
2800
1
1
8
118
50
720x380x830
39
CIRRUS 340100
01622
340
12
213
7.5
3
1 - 13A
2800
1
1
8
118
100
800x390x1070
55
Air
8
