700VDC Isolation
DESCRIPTION
TThe 1600 series are dual or quad isolation
transformer packs for use in digital circuits.
They are particularly suited to isolating
microprocessor bus connections and
performing logic level translation.
Being completely passive, power savings
are offered over opto-coupled or emitter
follower solutions.
1621
1630
1631
1635
1636
SWITCHING CHARACTERISTICS, 5V LOGIC
Parameter
Conditions
MAX
Units
Propagation delay, t
PD
Low-level pulse width
1
, t
LPW
High-level pulse width
1
, t
HPW
LSTTL Buffer drive
Other terminal to VCC
Other terminal to GND
5.0
5.0
5.0
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
Storage temperature range
Lead Temperature 1.5mm from case for 10 seconds
Isolation voltage (flash tested for 1 second)
Insulation resistance at 500VDC
0擄C to 70擄C
--40擄C to 125擄C
300擄C
700VDC
>10G鈩?/div>
NON-INVERTED +VE GOING PULSE
1
2
0V
Quad-Bus
Isolator
16
15
0V
NON-INVERTED 鈥揤E GOING PULSE
+5V
1
2
16
15
+5V
Quad-Bus
Isolator
INVERTED +VE GOING PULSE
+5V
1
2
0V
Quad-Bus
Isolator
16
15
INVERTED 鈥揤E GOING PULSE
+5V
1
2
16
15
0V
Quad-Bus
Isolator
www.cdpoweronline.com
1 The maximum pulse width limit to be applied to the repetition curve.
All specifications typical at T
A
=25擄C
Package
Style
ns
碌s
碌s
