Bulletin PD-20595 11/01

155CMQ015

SCHOTTKY RECTIFIER

150 Amp

Major Ratings and Characteristics

Characteristics

I

F(AV)

Rectangular waveform

(Per Device)

V

RRM

I

FSM

@ tp = 5 碌s sine

V

F

T

J

@ 75 Apk, T

J

= 125擄C

range

Description/ Features

Units

A

V

A

V

擄C

This center tap Schottky rectifier has been optimized for low

reverse leakage at high temperature. The proprietary barrier

technology allows for reliable operation up to 125擄 C junction

temperature. Typical applications are in switching power

supplies, converters, free-wheeling diodes, and reverse bat-

tery protection.

125擄 C T

J

operation (V

R

< 5V)

Isolated heatsink

Center tap module

Multiple leads per terminal for high frequency, high

current PC board mounting

High purity, high temperature epoxy encapsulation for

enhanced mechanical strength and moisture resistance

Low forward voltage drop

High frequency operation

Guard ring for enhanced ruggedness and long term

reliability

Values

150

15

8000

0.37

- 55 to 125

CASE STYLE AND DIMENSIONS

Outline D-60 (Modified JEDEC TO-249AA)

Dimensions in millimeters and inches

www.irf.com

1

next
