GaAs SIDE LOOK PACKAGE
INFRARED EMITTING DIODE
Description
The MIE-144G1 is a GaAs infrared emitting diode
molded in clear , lensed side looking package .
The MIE-144G1 provides a broad range of
intensity selection .
4.12
(.162)
1.22
(.048)
1.66鹵0.08
(.065鹵.003)
4.00鹵0.08
(.156鹵.003)
1.80
1.80
(.071)
(.071)
蠁
1.50
(.059)
MIE-144G1
Package Dimensions
Unit: mm( inches
)
1.10
(.043)
0.75
(.030)
1.50
(.059)
60擄
0.80
(.032)
2-
14.30MIN.
(.563)
0.5TYP.
(.020)
Features
l
Selected to specific on-line intensity and
radiant intensity ranges
1.0MIN.
(.039)
2.54鹵0.08
(.100鹵.003)
(SEE NOTE 3)
l
l
Low cost , plastic side looking package
Mechanically and spectrally matched to
The MID-14422 of phototransistor .
C
A
Notes :
1. All dimensions are in millimeters.(inches).
2. Protruded resin under flange is 1.5 mm (0.059") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current
Continuos Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
75
1
50
5
-55
o
C to +100
o
C
-55
o
C to +100
o
C
260
o
C for 5 seconds
Unit
mW
A
mA
V
Unity Opto Technology Co., Ltd.
02/04/2002
