AlGaAs/GaAs HIGH POWER SIDE LOOK PACKAGE
INFRARED EMITTING DIODE
MIE-144A1
Description
The MIE-144A1 is a GaAs infrared emitting diode
with AlGaAs Window layer, molded in clear, lensed
side looking package. The MIE-144A1 provides a
broad range of intensity selection .
1.22
(.048)
4.12
(.162)
2.90鹵0.12
(.114鹵.005)
60
0.65 max
5.70鹵0.30
(.224鹵.012)
0.80鹵0.07
(.032鹵.003)
4.00鹵0.07
(.156鹵.003)
1.80
(.070)
1.50
(.059)
Unit: mm( inches )
1.50鹵0.12
(.089鹵.005)
1.10鹵0.07
(.043鹵.003)
0.75鹵0.08
(.030鹵.003)
1.31鹵0.12
(.052鹵.005)
Features
l
Selected to specific on-line intensity and
radiant intensity ranges
1.0min
0.48鹵0.05
(.019鹵.002)
l
Low cost, plastic side looking package
2.54 鹵0.12
(.100鹵.005)
(SEE NOTE 3)
C
A
Notes :
1. All dimensions are in millimeters.(inches).
2. Protruded resin under flange is 1.5 mm (0.059") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current
Continuos Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
75
1
50
5
-55
o
C
to +100
o
C
-55
o
C
to +100
o
C
260
o
C
for 5 seconds
Unit
mW
A
mA
V
