SIDE LOOK PACKAGE
NPN PHOTOTRANSISTOR
Description
The MID-14422 is a NPN silicon phototransistor moun-
ted in a lensed ,water clear plastic and side looking package.
1.22
.048
4.00 鹵 .08
(.158鹵.003)
1.80
1.80
(.071)
(.071)
蠁
1.50
(.059)
MID-14422
Package Dimensions
Unit: mm ( inches )
1.10 鹵.80
(.043鹵.032)
0.75 鹵 0.8
(.030鹵.032)
1.50 鹵 .08
(.059鹵.032)
4.12
(.162)
1.66 鹵 .08
(.065鹵.003)
1.31 鹵 .12
(.052鹵.005)
60擄
Features
l
l
l
l
Wide range of collector current
Lensed for high sensitivity
Clear transparent package
Low cost plastic package
14.30MIN
(.563)
0.50 TYP.
(.020)
.80 鹵 .02
(.031鹵.001)
1.00MIN
(.039)
2.54
(.100)
C
E
Notes :
1. All dimensions are in millimeters. (inches).
2. LED die vertical & horizontal placement tolerance is 鹵 0.12 mm.
3. Protruded resin under flange is 1.5 mm (.059") max.
4. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Collector-Emitter Voltage
Emitter-Collector Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
100
30
5
Unit
mW
V
V
-55
o
C to +100
o
C
-55
o
C to +100
o
C
260
o
C for 5 seconds
Unity Opto Technology Co., Ltd.
02/04/2002
