ID 2023
V2.00
SMA
鈥?/div>
Intermodulation sensitive designs
鈥?/div>
Non-ferrous brass construction
鈥?/div>
Corrosion resistant, non-magnetic White Bronze
TM
plating
鈥?/div>
Fully crimpable, 3-piece flexible cable designs
M/A-COM introduces the SMA.com series of subminiature RF
connectors. SMA.com series are designed to satisfy the growing
demand for reliable, intermodulation sensitive performance in
wireless communications. The SMA.com series offers all the
advantages of, and is intermateable with, our standard range of
stainless steel SMA connectors but have been designed utilizing
non-ferrous brass materials and our unique White Bronze鈩?/div>
plating.
The SMA.com series meets the performance, quality and ease of
use requirements of the commercial marketplace. Our broad
range of connectors utilize fully crimpable 3-piece flexible cable
designs with mechanically captivated center contacts for
improved shielding. Thick wall plug interfaces ensure that
mechanical integrity is maintained when connectors are mated at
the specified torque value. Extended length ferrules increase
cable retention and provide added strain relief characteristics,
thereby eliminating the need for a supplementary shrink boot.
Rated for a minimum of 100 mating cycles, SMA.com guarantees
a mechanically robust threaded coupling connection even in the
most demanding applications. Standard plating of SMA.com is
White Bronze鈩? a unique finish developed by M/A-COM to
address the performance needs of the telecommunications
market. Highly resistant to corrosion and wear, White Bronze鈩?/div>
contains no ferrous materials and, as a result, displays excellent
intermodulation characteristics.
To satisfy a broad range of commercial applications, SMA.com
connectors are available in a variety of standard configurations,
including: straight and right angle cable plug, bulkhead cable
jack, two and four hole flange panel mount jack, and both straight
and right angle PCB jack. Additionally, between and in-series
adapters and cable assemblies can be supplied to meet your
specific packaging needs for integrating or testing component
and subsystem parameters.
Appropriate for a broad range of applications, SMA.com is espe-
cially suited for applications in cellular infrastructure where
Intermodulation Products (IMP) must be minimized. By limiting
non-linearities within the connector, SMA.com reduces IMP and
provides carriers increased channel capacity and efficiency.
Typical SMA.com Design
0
-10
(dB)
RETURN
LOSS
-20
-30
-40
-50
1
2
3
FREQUENCY
4
(GHz)
5
6
Typical Return Loss SMA.com Jack to Plug M
M/A-COM maintains an SPC controlled and ISO certified global
manufacturing environment to ensure unsurpassed quality. Call
your local M/A-COM sales office, global Applications Engineering
team, or authorized distributor for more information or samples
of the SMA.com connector series, and allow us to provide you
with a competitive advantage in design, manufacturing, and
installation.
Specifications Subject to Change Without Notice.
M/A-COM, Inc.
North America:
Tel. (800) 366-2266
Fax (800) 618-8883
s
1
Asia/Pacific: Tel. +85 2 2111 8088
Fax +85 2 2111 8087
s
Europe: Tel. +44 (1344) 869 595
Fax +44 (1344) 300 020
