SIDE LOOK PACKAGE
NPN PHOTODETECTOR
Description
The MID-11H22 is a NPN silicon phototransistor mounted
in a lensed , special dark plastic and side looking package.
4.45鹵0.12
(.175鹵.005)
2.22
(.087)
1.22鹵0.07
(.048鹵.003)
MID-11H22
Package Dimensions
Unit: mm ( inches )
0.76
(.030)
5.72鹵0.12
(.225鹵.005)
1.55鹵0.12
(.061鹵.005)
Features
l
Wide range of collector current
Lensed for high sensitivity
Low cost plastic package
Good spectral matching to IRED (位p >800 nm) type.
1.00 MIN.
(.040)
12.70 MIN.
(.500)
l
0.50 TYP.
(.020)
l
l
2.54
(.100)
E
C
Notes :
1. Tolerance for excess molding compound is 鹵 0.005".
2. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25 C
Parameter
Power Dissipation
Collector-Emitter Voltage
Emitter-Collector Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
100
30
5
-55 C to +100 C
-55
o
C to +100
o
C
260
o
C for 5 seconds
o
o
o
Unit
mW
V
V
